X5 FastMig
Operating manual - EN
1. Left control knob
2. Right control knob
3. Trigger logic selection (2T/4T)
4. Process selection (MIG/MMA/Gouging)
5. Home button (default welding mode)
6. Weld data button
7. Settings button
For using the control panel, refer to "Using X5 Manual control panel" on page74.
1.4.4 Auto control panel (X5 FP 300)
This section describes the controls and features of the X5 Wire Feeder 300 Auto control panel (TFT/LCD).
1. Left control knob (with push button function)
2. Right control knob (with push button function)
3. Memory channel selection (shortcut button)
4. View selection (shortcut button)
5. Welding parameters view (shortcut button).
For using the control panel, refer to "Using X5 Auto control panel" on page80.
© Kemppi
18
1920960 / 2144
