X8 MIG WELDER 2.4 Installation
1 2 3 4
2.
Install the front wheels.
a) Push the front axle through the opening in the bottom of the front side of the unit and set
the axle in the middle.
b) Place the transportation handle over the ridge in the wheel assembly and align the holes
in the wheel assembly with the ends of the axle.
c) Attach the front wheel assembly to the end of the axle with a bolt (1) and washer (2) from
both sides.
OPERATING MANUAL | EN 29
©
KEMPPI 2017 | 1817
