X8 MIG WELDER 2.4 Installation
21
Max. 20 Nm
d) When the wheels are attached, lift the power source off the pallet.
Note:
If your setup includes X8 Gas Cylinder Cart, proceed to Installing optional gas cylinder
cart.
2.4.2.2 Installing optional gas cylinder cart
To transport a larger gas cylinder with the power source, install X8 Gas Cylinder Cart. For detailed
instructions, see X8 Gas Cylinder Cart Mounting Instructions. If your setup does not include the
gas cylinder cart, proceed to Installing optional X8 Cooler.
1.
Remove the packaging from the sides but leave the power source resting on the pallet.
OPERATING MANUAL | EN 30
©
KEMPPI 2017 | 1817
