X8 MIG WELDER 2.4 Installation
Figure 4: Connecting to wire feeder Figure 5: Connecting to power source
b) Move focus to select the connection and press the green button.
Note:
The connection list shows the serial numbers of the available wire feeders and a
power source. Check the serial number on the device rating plate.
A connection forms between the wire feeder or power source and Control Pad. The led on
the power source lights up permanently.
Note:
Once you have created the connection, Control Pad tries to reconnect if you take
it out of the connection distance. Select Disconnect on Control Pad to disconnect
the connection.
2.
You can also connect Control Pad to the wire feeder through the wire feeder control panel if
the wire feeder is far from the power source.
a) Go to Settings > Wireless devices > Connect.
The wire feeder connects automatically to Control Pad.
3.
If the buttons of the power source and wire feeder are unreachable:
a) Go to Settings > WirelessDevicesAvailable in Control Pad.
OPERATING MANUAL | EN 57
©
KEMPPI 2017 | 1817
