KERN PLE - Page 39

PLE-BA-e-0812
39
• Set lower tolerance limit "Min"
000.000
Min
000.850
Min
− Select the point to be changed by pressing the button and the active
point flashes in each case.
− Select the figure by pressing the button
− Confirm the input lower tolerance limit by pressing the button
• Set the upper tolerance limit "Max"
000.000
Max
002.854
Max
− Select the point to be changed by pressing the button and the active
point flashes in each case.
− Select the figure by pressing the button
− Confirm the input upper tolerance limit by pressing the button
0.000
Min
a
The balance is now in checkweighing mode Put on goods to be weighed, tolerance
control is started
• Return to weighing mode
Press
button repeatedly
Information:
If invalid values are entered such as lower tolerance limit greater than upper
tolerance limit, the balance will issue the error message (-lo-) and return
automatically to weighing mode.
