13.3 Weighing with tolerance range (Function P4.4 HiLo)
For weighing with tolerance ranges you can enter individual upper and lower limits.
For tolerance controls such as dosaging, apportioning or sorting the scale will display
violated upper or lower limits and show the tolerance tag.
The tolerance marks (Min, Ok, Max) in the top section of the display indicate whether
the goods to be weighed are within the two tolerance limits.
The tolerance markers are only in operation during operating mode tolerance
weighing; they are otherwise not visible.
The tolerance marker provides the following information:
0.000
g
Min
Max
OK
Min
OK
Min
Goods to be weighed below tolerance limit
Ok
Goods to be weighed within tolerance
range
Max
Goods to be weighed above tolerance limit
• Call function
⇒
⇒
⇒
⇒
