Calibration Procedures 4
Keysight 33210A Service Guide 101
3 Using the numeric keypad, adjust the displayed amplitude at each setup to
match the measured amplitude (in dBm). Then select ENTER VALUE.
4 After performing setup 75:
Setup
Nominal Signal
Frequency Amplitude
63
[a]
[a] Constants are stored after completing this setup.
100 kHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
64
[a]
200 kHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
65
[a]
500 kHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
66
[a]
1.5 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
67
[a]
3.0 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
68
[a]
4.0 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
69
[a]
6.0 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
70
[a]
8.0 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
71
[a]
9.9 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Elliptical Filter
72
[a]
200 kHz 2.8 Vrms 22 dBm Flatness for 20 dB, Linear Phase Filter
73
[a]
500 kHz 2.8 Vrms 22 dBm Flatness for 20 dB, Linear Phase Filter
74
[a]
1.5 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Linear Phase Filter
75
[a]
3.0 MHz 2.8 Vrms 22 dBm Flatness for 20 dB, Linear Phase Filter
In order to get dBm you must use the numeric keypad (not the knob) to enter the
number, and then select “dBm”.
