INPut3:COUPling {AC | DC}, (@<ch_list>)
INPut3:COUPling?(@<ch_list>)
Sets the input coupling to either AC or DC on the specified channels.
This SCPI is supported on the DAQM909A Digitizer module only.
Parameter Typical return
{ AC | DC }
Default: DC
<ch_list> = specified channels to be configured
AC, or DC
Sets DC input coupling to channels 201 and 202:
INP3:COUP DC,(@201,202)
INPut3:TYPE {DIFFerential | SENDed | IEPE}, (@<ch_list>)
INPut3:TYPE? (@<ch_list>)
Sets the input type to either differential or single-ended on the specified channels. Select IEPE if the channel input
terminal is connected with an IEPE sensor.
This SCPI is supported on the DAQM909A Digitizer module only.
Parameter Typical return
{ DIFF | SEND | IEPE }
Default: DIFF
<ch_list> = specified channels to be configured
DIFF, SEND, or IEPE
Sets SEND input type to channels 201 and 202:
INP3:COUP SEND,(@201,202)
158
Keysight DAQ970A/DAQ973A Programming Guide
2 SCPI Programming
