MEASure:DAC:OUTPut? (@<ch_list>)
Only supported on DAC output channels (channel 04 and 05) in DAQM907A multifunction module.
Configures the specified DAC output channels for unbuffered (no memory) input operations and immediately
sweeps through the channels one time (independent of the present scan list). The results are sent directly to reading
memory and the instrument's output buffer. This command redefines the scan list.
Parameter Typical return
(none) (none)
Configure a default DACoutput measurement on channel 104:
MEAS:DAC:OUTP? (@104)
Typical Response: +1.32130000E-01
– There is no actual measurement on this command. Executing this command will simply return the
"PROGRAMMED" DAC settings. For example, sets the value to 1.234 V will exactly return 1.234 V on the sub-
sequent sweep of scanning.
– This command is useful when using DAC to control the measurements, varying the output from time-to-time,
and record the sweep data of DAC settings in fact for that sweep.
MEASure:DAC:SENSe? (@<ch_list>)
Only supported on DAC output sense channels (channel 06 and 07) in DAQM907A multifunction module.
Configures the specified DAC output sense channels for unbuffered (no memory) input operations and immediately
sweeps through the channels one time (independent of the present scan list). The results are sent directly to reading
memory and the instrument's output buffer. This command redefines the scan list.
Parameter Typical return
(none) (none)
Configure a default DACsense measurement on channel 106:
MEAS:DAC:SENS? (@106)
Typical Response: +1.32130000E-01
– This command does makes an actual measurement. The range and resolution are fixed at 1 PLC on the 10
VDCrange.
– Channel 06 will make the measurement based on the output mode set in channel 04 of DAC output channel;
channel 07 will make the actual measurement based on the output mode set in channel 05 of DAC output
channel.
Keysight DAQ970A/DAQ973A Programming Guide 167
2 SCPI Programming
