SAMPle3:COUNt {<count> | MIN | MAX | DEF}, (@<ch_list>)
SAMPle3:COUNt? {(@<ch_list>) | MIN | MAX | DEF}
Sets the number of measurements (samples) the instrument takes per trigger on the specified channels.
These SCPIs are supported on the DAQM909A Digitizer module only.
Parameter Typical return
<count> = 1 to 50,331,584 samples
MIN: 512
MAX: Refer to the table below.
Number of DAQM909A installed SAMPle3:COUNt MAX
1 DAQM909A card installed 50331584
2 DAQM909A cards installed 25165760
3 DAQM909A cards installed 16777152
DEF: 512
+512
Sets digitizer channel 201 to take 1000 samples per trigger
SAMP3:COUN 1000,(@201)
– The maximum allowed sample count for a channel is 48 MSa if one digitizer module installed; 24 MSa if two
digitizer modules installed, and 16MSa if three digitizer modules installed.
Keysight DAQ970A/DAQ973A Programming Guide 221
2 SCPI Programming
