TRIGger3:WFTRigger?
Returns the "wait-for-trigger" status for all the DAQM909A digitizer channels.
These SCPIs are supported on the DAQM909A Digitizer module only.
Parameter Typical return
None +0
– Table below shows the bits and the corresponding channels and slots. Bit 0 to bit 3 are for the channels on slot
100, bit 4 to bit 7 are for the channels on slot 200, and bit 8 to bit 11 are for the channels on slot 300.
Bits DAQ970A/DAQ973A slot Digitizer channels
Bits 0 - 3 100 101,102,103,104
Bits 4 - 7 200 201, 202, 203, 204
Bits 8 - 11 300 301, 302, 303, 304
– The bit value of 1 indicates the channel is in the "wait-for-trigger" state.
Keysight DAQ970A/DAQ973A Programming Guide 349
2 SCPI Programming
