ACQuire3:STRain:{HALF|FULL}:BENDing [{<gage_factor> | MIN | MAX | DEF},
[{<excitation_voltage> | MIN | MAX | DEF}, [{<range> | MIN | MAX | DEF},
[{DIFFerential | SENDed | DEF}, [{AC | DC | DEF}, [{TIME | FREQuency | DEF},
[{<samp_count> | MIN | MAX | DEF}, [{<samp_rate> | MIN | MAX | DEF},]]]]]]]] (@<ch_list>)
Configures the channels for full or half bending bridge strain gage module digitizing, but they do not initiate the
digitizing.
This SCPI is supported on the DAQM909A Digitizer module only.
Parameter Typical return
<gage_factor>
MIN: 0.5
MAX: 5
DEF: 2
<excitation voltage>
MIN: 0.9 V
MAX: 12 V
DEF: 5 V
<range> = { 300 mV |1 V | 3 V | 18 V }
MIN: 300 mV
MAX: 18 V
DEF: 1 V
<type> = { DIFF | SEND |DEF }
Default = DIFF
<coupling> = { AC | DC | DEF }
Default = DC
<mode> = { TIME |FREQ | DEF }
Default = TIME
<samp_count>
MIN: 512
MAX: 50,331, 584
DEF: 512
<samp_rate> = { 1.5625 K | 3.125 K |6.25 K | 12.5 K | 25 K | 50 K | 100 K | 200 K | 400 K | 800 K }
MIN: 1.5625 K
MAX: 800 K
DEF: 100 K
(none)
Configures a default half bending bridge strain gage module digitizing on Channel 201:
ACQ3:STR:HALF:BEND DEF,DEF,DEF,DEF,DEF,DEF,DEF,DEF,(@201)
