ACQuire3:VOLTage[:DC] [{<range> | MIN | MAX | DEF}, [{DIFFerential | SENDed | DEF},
[{AC | DC | DEF}, [{TIME | FREQuency | DEF}, [{<samp_count> | MIN | MAX | DEF},
[{<samp_rate> | MIN | MAX | DEF},]]]]]] (@<ch_list>)
Configures the channels for DC voltage module digitizing, but they do not initiate the digitizing.
This SCPI is supported on the DAQM909A Digitizer module only.
Parameter Typical return
<range> = { 300 mV | 1 V | 3 V | 18 V }
MIN: 300 mV
MAX: 18 V
DEF: 1 V
<type> = { DIFF | SEND |DEF }
Default = DIFF
<coupling> = { AC | DC | DEF }
Default = DC
<mode> = { TIME |FREQ | DEF }
Default = TIME
<samp_count>
MIN: 1
MAX: 50,331,584
DEF: 1
<samp_rate> = { 1.5625 K | 3.125 K |6.25 K | 12.5 K | 25 K | 50 K | 100 K | 200 K | 400 K | 800 K }
MIN: 1.5625 K
MAX: 800 K
DEF: 100 K
(none)
Configures a default DC voltage module digitizing on Channel 201:
ACQ3:VOLT DEF,DEF,DEF,DEF,DEF,DEF,(@201)
54
Keysight DAQ970A/DAQ973A Programming Guide
2 SCPI Programming
