Keysight E5260/E5270 Programming Guide, Edition 4 4- 43
Command Reference
Command Reference
CL
The CL command disables the specified channels by setting the output switches to
OFF. Then the channel output is opened, and the power consumption is 0 W.
Execution
Conditions
No channel may be in the HIGH VOLTAGE state (forcing more than ±42 V, or
voltage compliance set to more than ±42 V). However, if you do not specify chnum
for CL command, there are no restrictions on the execution conditions.
Syntax CL [chnum[,chnum...[,chnum]...]]
A maximum of eight channels can be set.
Parameters chnum : Channel number. The value must be slot number where the module has
been installed. Integer expression. 1 to 8 (1 and 5 are not available for
HPSMU). See
Table 4-1 on page 4-9.
If you specify multiple chnums, the E5260/E5270 sets the channels to 0 V in the
specified order.
If you do not specify chnum, this command sets all channels to 0 V in order from
higher voltage range (output or measurement range) to lower voltage range.
Remarks The CL command sets the specified channels to the following conditions:
Example
Statements
OUTPUT @E5270;"CL"
OUTPUT @E5270;"CL 1,2,3,5"
Item Setting Item Setting
Output Switch OFF I Compliance 100 μA
Source Mode Voltage I Range 100 μA
Output Voltage 0 V Filter OFF
V Range 20 V Series Resistor Not changed
