4- 82 Keysight E5260/E5270 Programming Guide, Edition 4
Command Reference
Command Reference
MM
The MM command specifies the measurement mode and the channels used for
measurements. This command must be entered to specify the measurement mode.
For the high speed spot measurements, do not enter the MM command.
Syntax • For spot, staircase sweep, and multi channel sweep:
MM mode,chnum[,chnum[,chnum...[,chnum]...]]
A maximum of eight channels can be set.
• For pulsed spot, pulsed sweep, and staircase sweep with pulsed bias:
MM mode,chnum
• For binary search and linear search:
MM mode
• For quasi pulsed spot:
MM mode[,chnum]
Parameters mode : Measurement mode. Integer expression. 1 to 5, 9, and 14 to 16.
chnum: Measurement channel number. The value must be slot number where
the module has been installed. Integer expression. 1 to 8 (1 and 5 are
not available for HPSMU). See
Table 4-1 on page 4-9.
mode Measurement mode Related source setup command
1 Spot DI, DV
2 Staircase sweep WI, WV, WT, WM, WSI, WSV
3 Pulsed spot PI, PV, PT
4 Pulsed sweep PWI, PWV, PT, WM, WSI, WSV
5 Staircase sweep with
pulsed
bias
WI, WV, WM, WSI, WSV, PI, PV, PT
9 Quasi-pulsed spot BDV, BDT, BDM
14 Linear search LSV, LSI, LGV, LGI, LSM, LSTM,
LSSV, LSSI, LSVM
15 Binary search BSV, BSI, BGV, BGI, BSM, BST,
BSSV, BSSI, BSVM
16 Multi channel sweep WI, WV, WT, WM, WNX
