Keysight E5260/E5270 Programming Guide, Edition 4 4- 115
Command Reference
Command Reference
Table 4-12 Trigger Type
Example
Statements
OUTPUT @E5270;"TGP 1,1,1,2"
See Also See Figure 4-2 on page 4-113 for a trigger output example and Figure 4-3 on page
4-117 for a trigger input example.
type terminal Description
0 1 When a trigger is received, the E5260/E5270 recovers from the wait state set by
the PA, PAX, WS, or WSX command.
2 The E5260/E5270 sends a trigger by the OS or OSX command.
1
a
a. TM3 command must be entered to use this trigger type.
1 Start measurement trigger
When a trigger is received, the E5260/E5270 starts the measurement.
2 Measurement completion trigger
The E5260/E5270 sends a trigger after measurement.
2 1 Start step output setup trigger
When a trigger is received, the E5260/E5270 starts the output setup at each
sweep step or the pulsed output setup. This function is available for the staircase
sweep, pulsed sweep, staircase sweep with pulsed bias, multi channel sweep, or
pulsed spot measurement.
2 Step output setup completion trigger
The E5260/E5270 sends a trigger when the output setup is completed at each
sweep step or the pulsed output setup is completed. This function is available for
the staircase sweep, pulsed sweep, staircase sweep with pulsed bias, multi
channel sweep, or pulsed spot measurement.
3 1 Start step measurement trigger
When a trigger is received, the E5260/E5270 starts the measurement at each
sweep step. This function is available for the staircase sweep or multi channel
sweep measurement.
2 Step measurement completion trigger
The E5260/E5270 sends a trigger after measurement at each sweep step. This
function is available for the staircase sweep or multi channel sweep
measurement.
