Front and Rear Panel Functions
Rear Panel Features
Rear Panel Features
Figure 5-2 UXM 5G Rear Panel
The regions of the rear panel that are outlined in the illustration are described
in the following sections.
Do not cover or block the air flow vents. The test platform draws air in from the
left side and exhausts air from the right side.
The main power cord can be used as the system disconnecting device. It
disconnects the mains circuits from the mains supply.
