Symbol Description
This symbol is used to indicate power ON.
This symbol is used to indicate power OFF.
This symbol is used to indicate power STANDBY mode (yellow in standby, green when instrument
is ON).
This symbol indicates the input power required is AC.
This symbol indicates earth ground.
The instruction documentation symbol. The product is marked with this symbol when it is
necessary for the user to refer to instructions in the documentation.
The CE mark is a registered trademark of the European Community.
The RCM Mark is a Compliance Mark according to the ACMA Labeling Requirement.
South Korean Certification (KC) mark; includes the marking’s identifier code which follows this
format: MSIP-REM-YYY-ZZZZZZZZZZZZZZ
ICES / NMB-001 Cet appareil ISM est conforme a la norme NMB du Canada. This is a marking to
indicate product compliance with the Industry Canadian Interference-Causing Equipment
Standard (ICES-001).
This is also a symbol of an Industrial Scientific and Medical Group 1 Class A product (CISPR 11,
Clause 4).
The CSA mark is a registered trademark of the CSA International.
This symbol indicates separate collection for electrical and electronic equipment mandated under
EU law as of August 13, 2005. All electric and electronic equipment are required to be separated
from normal waste for disposal (Reference WEEE Directive 2002/96/EC).
