78 Getting Started Guide
Front and Rear Panel Functions
Rear Panel Features
FPGA Expansion Module (E7515B-FP1)
Figure 5-5 UXM 5G Rear Panel -- E7515B-FP1 card connectors
These connectors relate to the optional FPGA expansion module
(E7515B-FP1), of which there are potentially two, located in slots 1 and 3.
These modules expand the FPGA capacity of the E7515B, for certain kinds of
5G testing which require this.
Name Description Notes
QSFP1 Kintex-A QSFP Interface Reserved for future use.
QSFP0 Kintex-A QSFP Interface Reserved for future use.
TRIG 1 TBD Reserved for future use.
DEBUG TBD Reserved for future use.
TRIG 0 TBD Reserved for future use.
