Getting Started Guide 83
Front and Rear Panel Functions
Rear Panel Features
RFIO
Figure 5-10 UXM 5G Rear Panel -- RFIO Connectors
These connectors relate to the RFIO circuit board within the UXM 5G.
AC Power
Removing the main power cord disconnects the mains circuits from the mains
supply, and can be used as the system disconnecting device.
Name Description Notes
IF IN 3 SMA (Reserved for future use.)
IF IN 4 SMA (Reserved for future use.)
IF OUT 8 SMA (Reserved for future use.)
IF OUT 7 SMA (Reserved for future use.)
IF OUT 6 SMA (Reserved for future use.)
IF OUT 5 SMA (Reserved for future use.)
IF IN 1 SMA (Reserved for future use.)
IF IN 2 SMA (Reserved for future use.)
IF OUT 4 SMA (Reserved for future use.)
IF OUT 3 SMA (Reserved for future use.)
IF OUT 2 SMA (Reserved for future use.)
IF OUT 1 SMA (Reserved for future use.)
