Performance Tests and Calibration 6
Keysight U1251B and U1252B User’s and Service Guide 167
Valid adjustment input values
Adjustment can be accomplished using the following input values.
Table 6-3 Valid adjustment input values
Function Range Valid amplitude input values
5 V, 50 V, 500 V, 1000 V 0.9 to 1.1 x Full Scale
(for U1251B)
5 V, 50 V, 500 V, 1000 V 0.9 to 1.1 x Full Scale
(for U1252B)
5 V, 50 V,500 V, 1000 V 0.9 to 1.1 x Full Scale
50 mV, 500 mV, 1000 mV 0.9 to 1.1 x Full Scale
500 μA, 5000 μA 0.9 to 1.1 x Full Scale
50 mA, 440 mA, 5 A, 10 A 0.9 to 1.1 x Full Scale
500 , 5 k, 50 k, 500 k, 5 M, 50 M 0.9 to 1.1 x Full Scale
Diode 0.9 to 1.1 x Full Scale
/
10 nF, 100 nF, 1000 nF, 10 μF, 100 μF,
1000 μF, 10 mF / 0 C
Make sure to provide 0 C with ambient
compensation
