Measuring AC voltage
Set up the multimeter to measure AC voltage as shown in Figure 2-1. Probe the
test points and read the display.
Figure 2-1 Measuring AC voltage
Red Lead
Black Lead
NOTE
Press to display frequency on the secondary display. See Table 1-8 of
“Selecting display with the Dual button” on page 42 for a list of the different
combinations available on the secondary display.
