Keysight U1252B - Measuring Resistance, Conductance and Testing Continuity; Figure 2-7 Measuring Resistance

Making Measurements 2
Keysight U1251B and U1252B User’s and Service Guide 61
Measuring Resistance, Conductance and Testing Continuity
Set up the multimeter to measure resistance as shown in Figure 2-7. Then probe
the test points (by shunting the resistor) and read the display.
Figure 2-7 Measuring resistance
CAUTION
Disconnect the circuit power and discharge all high-voltage capacitors
before measuring resistance to prevent any possible damage to the
multimeter or the device under test.
Red Lead
Black Lead
