1 Quick Start
Instrument Information
Instrument Information
Power requirements
The only physical installation of your Keysight signal analyzer is a connection to a
power source. Line voltage does not need to be selected.
This instrument has auto-ranging line voltage input; be sure the supply voltage is within
the specified range and that voltage fluctuations do not to exceed 10 percent of the
nominal supply voltage.
This analyzer does not contain customer serviceable fuses.
The instruments can operate with mains supply voltage fluctuations up to ±10% of the
nominal voltage.
This is a Safety Class 1 Product (provided with a protective earthing ground
incorporated in the power cord). The mains plug shall only be inserted in a
socket outlet provided with a protective earth contact. Any interruption of the
protective conductor inside or outside of the product is likely to make the
product dangerous. Intentional interruption is prohibited.
Failure to ground the analyzer properly can result in personal injury. Before
turning on the analyzer, you must connect its protective earth terminals to the
protective conductor of the main power cable. Insert the main power cable plug
into a socket outlet that has a protective earth contact only. DO NOT defeat the
earth-grounding protection by using an extension cable, power cable, or
autotransformer without a protective ground conductor.
The Mains wiring and connectors shall be compatible with the connector used in the
premise electrical system. Failure, to ensure adequate earth grounding by not using the
correct components may cause product damage, and serious injury.
AC Power Cords
The analyzer is equipped with a three-wire power cord, in accordance with
international safety standards. This cable grounds the analyzer cabinet when
connected to an appropriate power line outlet. The cable appropriate to the original
shipping location is included with the analyzer. Use Keysight supplied power cord or
one with same or better electrical rating. See:
http://www.keysight.com/find/powercords
Always use the three-prong AC power cord supplied with this product. Failure to ensure
adequate earth grounding by not using this cord can cause product damage.
14 Getting Started and Troubleshooting Guide
