Chapter 4: Using the DVR
52
DVR User’s Manual
4.4 Seng the Network
To enable remote monitoring, recording, playing, or conguring the seng via KGUARD Web Client or Kview Center
soware, you need to congure the network sengs and setup port forwarding in Router. Consult your Internet
Service Provider (ISP) to determine the type of network connecon you are using and the required parameters to
complete the setup.
4.4.1 Network Sengs
You can use the Network menu to setup how the DVR connects to the network. It provides three network connecon
opons: Stac IP, DHCP, and PPPoE.
1 In preview mode, right-click on the mouse to display the Pop-up menu.
2 Select Main Menu > NETWORK.
3 On Type, select the type of network connecon you are using.
• DCHP: With Dynamic Host Conguraon Protocol
(DHCP) service, your router will automacally assign
an IP address to your computer connected to the
network.
• PPPoE: The Point-to-Point Protocol over Ethernet
(PPPoE) is a network protocol for encapsulang
Point-to-Point Protocol (PPP) frames inside Ethernet
frames. This network protocol allows the device to
be directly connected using a DSL modem.
• Stac IP: This network protocol allows you to
congure the network interface using a xed IP
address.
4 Specify the Client Port and HTTP Port numbers.
• Client Port: Specify the port number that the device will use to send DVR command and video stream.
• HTTP Port: Specify the port number that you will use to log in to the device.
