Kikusui PLZ-U Series User Manual

6-10 Remote Control PLZ-U
6.4 Interface Setup
The factory default remote control interface setting is GPIB.
6.4.1 GPIB Control
■ GPIB connection
Use a standard IEEE488 cable to connect the PLZ-U to the PC.
■ Setting the GPIB address
1. Check that the load is turned off.
Check that the LOAD LED is turned off. If it is on, press the LOAD key to turn
it off.
2.
Enter CONFIG settings.
Press the CONFIG (SHIFT + CLEAR) key.
“CF. 01” appears on the frame display.
3.
Select the interface.
Turn the rotary knob and set the configuration number to 9 (CF. 09).
While holding down the SHIFT key turn the rotary knob to select GPIB.
4.
Set the address.
Turn the rotary knob and set the configuration number to 10 (CF. 10).
While holding down the SHIFT key turn the rotary knob to select the address.
5.
Power cycle the PLZ-U.
The settings are entered.
