6-8 Remote Control PLZ-U
Program parameters
Below are the definitions of the parameters used in this manual for denoting SCPI
commands.
conductance
A numeric data including MAXimum and MINimum.
• Program data
Unit SIE
current
A numeric data including MAXimum and MINimum.
• Program data
Unit A
status-enable
A 16-bit status mask for the CONDition register that determines which bits are to be
used.
Value 0 to 65535
step
A step number of a sequence program. Up to 256 steps can be used.
string
A string data. ASCII codes 20H to 7EH can be used.
time
The execution time of sequence mode.
Value 0.001 to 9999 or 0 (end step)
Resolution 0.001
Unit S
Range PLZ150U PLZ70UA
H
Selectable range 20 to 2 2 to 0 10 to 1 1 to 0
Resolution 2 m 0.2 m 1 m 0.1 m
M
Selectable range 2 to 200 m 200 m to 0 1 to 100 m 100 m to 0
Resolution 0.2 m 20 μ 0.1 m 10 μ
L
Selectable range 200 m to 20 m 20 m to 0 100 m to 10 m 10 m to 0
Resolution 20 μ 2 μ 10 μ 1 μ
Range PLZ150U PLZ70UA
H
Selectable range 0 to 31.500 0 to 15.75
Resolution 2 m 1 m
M
Selectable range 0 to 3.1500 0 to 1.575
Resolution 0.2 m 0.1 m
L
Selectable range 0 m to 315.00 m 0 m to 157.50 m
Resolution 0.02 m 0.01 m
