8-6 Specifications PLZ-U
*1. The time for updating the setting in CR or CV mode is approximately 100 ms.
General Specifications
External analog control
Power output 12 V and maximum output current of 50 mA.
External voltage control input
*1
Operates in CC, CR, and CV modes.
0 % to 100 % of f.s in the range of 0 V to 10 V.
Load-on input. Low active (or high active), pull up to 5 V using 10 kΩ.
Low level input voltage: 0 V to 1 V, high level input voltage: 4 V
to 5 V
Current monitor output 0 % to 100 % of the rated current in the range of 0 V to 10 V
Common Negative pin electric potential of the load input terminal
GPIB IEEE std. 488.2-1994
SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0, and E1
Supports the SCPI command set
Sets panel functions except the POWER switch and key lock and
reads measured values
RS-232C D-SUB 9-pin connector (conforms to EIA-232-D)
Sets panel functions except the POWER switch and key lock and
reads measured values
Baud rate: 2400, 4800, 9600, or 19200 bps; stop bit: 1; data
length: 8 bits; parity: NONE; and flow control: XON/OFF.
Model PLZ150U PLZ70UA
Weight Approx. 2 kg
Accessories
Rear load input terminal cover
1 pc.
Set of screws for the load
input connector
2 sets (M6 bolt, M6 nut, M6 spring washer, M4 screw)
Load unit attachment screws 2 pcs. (M3-10 screws, attached to the load unit)
Sensing terminal screw on
the rear panel
2 pcs. (M3-6 screws, attached to the load unit)
