PLZ-U Application Operation 5-9
5.6 Sequence Function
Sequence is a function that automatically runs a stored program one step at a time in
CC mode or CR mode. By specifying the setting and execution time of each step,
various waveform simulations can be executed.
The program is independent for each channel. The program is saved even when the
power is turned off through the backup function. The execution of the sequence
function starts when you press the LOAD key.
In CC mode, soft start is activated when the execution of the sequence starts.
■ Step settings
You enter the setting and execution time for each step. You can set up to 255 steps.
You can select whether to turn off the load or keep the load turned on when the
sequence completes.
• Step numbers 1 to 256 (the 256
th
step cannot be executed)
• Step execution time 1 ms to 9999 s. 0 specifies the end of the step.
• Number of program loops 0 to 9998. 9999 specifies infinite repetitions.
5.6.1 Editing the Sequence
1. Turn off the load.
2.
Select the channel.
Press the ENTRY key of the desired channel.
The channel display illuminates, and the ENTRY key of the channel
blinks.
3.
Set the operation mode and range.
Press the CC or CR key to select the operation mode.
The CC or CR key illuminates and the operation mode is entered.
Press the RANGE key to set the CC/CR range.
Each time you press the RANGE key, the range LED illuminates in the
order L (Low), M (Mid), and H (High), and the range is switched.
Program
Step 1
Step 2
Step 3
Step 256
Repeat
• • •
To Next Page
