6-14 Remote Control PLZ-U
*RCL
Recalls the contents saved to the memory (0 to 3). The range of parameters that are
configured are the same as the range of parameters initialized by the *RST com-
mand. For a description of the commands that are affected, see appendix A.5, “SCPI
Command Reference.”
Set command: *RCL <value>
• Program data
Value 0 to 3: Memory number
Resolution 1
*RST
Resets the device to factory default settings. CONFIG number 1 and 9 to 11 in the
configuration settings are not changed.
The settings after initialization are as follows:
Item PLZ150U PLZ70UA PLZ30F/PLZ50F
Current range H H -
Voltage range H H -
Operation mode CC CC -
CC mode SET value 0.000 A 0.000 A -
CR mode SET value 0.0 S 0.0 S -
CV mode SET value 157.50 V 157.50 V -
Switching function Off Off -
CC switching level 0 A 0 A -
CR switching level 0 S 0 S -
Switching frequency 1.000k Hz 1.000k Hz -
Switching duty cycle 50.0 % 50.0 % -
Slew rate 2.4 A/μs 1.2 A/μs-
Soft start 1.0 ms 1.0 ms -
OCP trip point 33.00 A 16.5 A -
OPP trip point 165.0 W 82.5 W -
UVP trip point Off Off -
LOAD OFF TIMER Off Off -
Sequence mode Off Off -
Operation mode CC CC
Current range H RANGE H RANGE
Step setting 0.000 A 0.000 A
Step execution time 0 ms 0 ms
RPT 1 1
SEQ STEP 1-256 0.000 A, 0 ms 0.000 A, 0 ms -
SEQ REPEAT 1 1 -
Load Off Off OFF
ENTRY - - CH1
INDEP Off Off -
DISP Voltage and current Voltage and current -
