6-38 Remote Control PLZ-U
OPERation:INSTrument:ISUMmary<n> subregister
Bit <n> subregister of the OPERation:INSTrument subregister.
For example, channel 2 (INSTrument2) is OPERation:INSTrument:ISUMmary2.
The <n> values that can be used for the PLZ-U are 1 to 5.
Table 6-5 OPERation:INSTrument:ISUMmary status register
(STATus:OPERation:INSTrument:ISUMmary)
STAT:OPER:INST:ISUM
Queries the event of the OPERation:INSTrument:ISUMmary subregister.
Query command: STATus:OPERation:INSTrument
:ISUMmary<n>[:EVENt]?
STAT:OPER:INST:ISUM:COND
Queries the condition of the OPERation:INSTrument:ISUMmary subregister.
Query command: STATus:OPERation:INSTrument
:ISUMmary<n>:CONDition?
STAT:OPER:INST:ISUM:ENAB
Sets the OPERation:INSTrument:ISUMmary subregister enable, or queries the cur-
rent setting.
Set command: STATus:OPERation:INSTrument
:ISUMmary<n>:ENABle <status-enable>
Query command: STATus:OPERation:INSTrument
:ISUMamry<n>:ENABle?
Bit Bit Weight Bit Name Description
0 1 CALibrating The PLZ-U is in calibration (CAL) mode.
1 2 NOT USED
2 4 NOT USED
3 8 NOT USED
4 16 NOT USED
532
Waiting for TRIGger Summary Indicates whether the PLZ-U is waiting for
a trigger (TRIG).
6 64 NOT USED
7 128 NOT USED
8 256 NOT USED
9 512 NOT USED
10 1024 NOT USED
11 2048 NOT USED
12 4096 NOT USED
13 8192 NOT USED
14 16384 NOT USED
15 32768 NOT USED Always zero
