6-40 Remote Control PLZ-U
QUEStionable status register
The QUEStionable status register is a 16-bit register that stores information related
to the questionable events and status during PLZ-U operation.
These register bits may indicate problems with the output of the PLZ-U.
Of the bits defined by SCPI, bits 0, 1, 3, and 4 are used.
In addition, bits 9, 10, and 11 are used as dedicated bits of the PLZ-U.
Table 6-6 QUEStionable status register (STATus:QUEStionable)
STAT:QUES
Queries the event of the QUEStionable status register.
Query command: STATus:QUEStionable[:EVENt]?
STAT:QUES:COND
Queries the condition of the QUEStionable status register.
Query command: STATus:QUEStionable:CONDition?
STAT:QUES:ENAB
Sets the QUEStionable status register enable, or queries the current setting.
Set command: STATus:QUEStionable:ENABle
<status-enable>
Query command: STATus:QUEStionable:ENABle?
STAT:QUES:PTR
Sets the positive transition of the QUEStionable status register, or queries the cur-
rent setting.
Set command: STATus:QUEStionable:PTRansition
<status-enable>
Query command: STATus:QUEStionable:PTRansition?
Bit Bit Weight Bit Name Description
0 1 OV Over Voltage
1 2 OC Over Current
2 4 Not Used
3 8 OP Over Power
4 16 OT Over Temperature
5 32 Not Used
6 64 Not Used
7 128 Not Used
8 256 Not Used
9 512 UV Under Voltage
10 1024 EXT External Problem
11 2048 REV Reverse Voltage
12 4096 Not Used
13 8192 INSTrument Summary
14 16384 Not Used
15 32768 Not Used Always zero
