10
10
Model
(G：
Constant
torque
load；
L：Fan
pump
load)
Shape
and
insta
llation
dimensions
(mm)
Weight
(Kg)
W
H
D
W1
H1
D1
Mounting
holes(d)
FV20-4T-0055G
/0075L
146
256
181
131
243
95
5.8
6
FV20-4T-0075G
/0110L
FV20-4T-0110G
/0150L
170
320
207
151
303
118.5
5.8
8
FV20-4T-0150G
/0185L
FV20-4T-0185G
/0220L
FV20-4T-0220G
/0300L
214
410
230
166
393
109
7
18
FV20-4T-0300G
/0370L
FV20-4T-0370G
/0450L
250
460
238
190
442
120
7
31
FV20-4T-0450G
/0550L
FV20-4T-0550G
/0750L
373
649
262
240
628
102.5
10
42
FV20-4T-0750G
/0900L
FV20-4T-0900G
/1100L
440
758
285
340
737
102
11
73
FV20-4T-1100G
/1320L
430
780
330
280
755
168
11
76
FV20-4T-1320G
/1600L
FV20-4T-1600G
/1850L
530
940
380
340
910
206
14
114
FV20-4T-1850G
/2000L
FV20-4T-2000G
/2200L
FV20-4T-2200G
/2500L
690
1006
380
500
974
207
14
156
FV20-4T-2500G
/2800L
FV20-4T-2800G
/3150L
FV20-4T-3150G
/3550L
810
1228
400
520
1196
209
14
225
FV20-4T-3550G
/4000L
FV20-4T-4000G
/4500L
FV20-4T-6000G
810
1328
400
520
1296
/
14
450
FV20-4T-8000G
FV20-4T-1000
0G
1480
1807
600
Seat
Type
Mounting
W1*H1=1040*
440
d=14
460
13
15
Table of Contents
Default Chapter
3
Table of Contents
3
Chapter 1 Safety
5
Safety
5
Notes for Installations
5
Notes for Using FV20
5
About Motor and Load
5
About Variable Frequency Drive
6
Disposing Unwanted Driver
7
Chapter 2 Product Introduction
8
Nameplate Introduction
8
Model Description
8
General Specifications
9
Introduction of Product Series
10
Structure of VFD
12
External Dimension and Weight
12
Operation Panel and Installation Box
15
Braking Resistor Selection
16
Chapter 3 Installation Environment
17
Installation Environment Requirements
17
Inverter Standard Peripheral Configuration
18
Chapter 4 Wiring Guide of VFD
20
Wiring and Configuration of Main Circuit Terminal
20
Terminal Type of Main Loop's Input and Output
20
Wiring of Main Loop
21
Wiring of VFD for Basic Operation
22
Wiring and Configuration of Control Circuit
22
Chapter 5 Operation Instructions of Kinco VFD
28
Using Operation Panel
28
Operation Panel Appearance and Keys' Function Description
28
Display Status of Operation Panel
29
Panel Operation
30
Operation Mode of VFD
32
Control Mode of VFD
32
Operating Status
32
Control Mode and Operation Mode of Kinco VFD
32
The Channels to Set the VFD Frequency
33
Power on the Drive for the First Time
34
Checking before Power on
34
Operations When Start up the First Time
34
Chapter 6 Parameter Introductions
35
Group A0
35
Group A1
37
Group A2
39
Group A3
41
Group A4
43
Group A5
44
Group A6
46
Group A7
55
Group A8
56
Group B0
57
Group B1
59
Group B2
60
Group B3
62
Group B4
62
Group C0
63
Group C1
63
Group C2
67
Group C3
69
Group D0
71
Group D1
72
Group D2
73
Chapter 7 Troubleshooting
74
Chapter 8 Maintenance
77
Daily Maintenance
77
Periodical Maintenance
77
Replacing Wearing Parts
78
Storage
78
Chapter 9 List of Parameters
79
Chapter 10 Communication Protocol
106
Networking Mode
106
Interfaces
106
Communication Modes
106
Protocol Format
106
RTU Mode
107
ASCII Mode
107
Protocol Function
108
Control Parameters and Status Parameters of VFD
108
Some Instructions
113
Application Example
114
Chapter 11 Basic Adjustment Guide
116
Motor Parameter Self-Tuning
116
Start by Terminal, Fr Equency Given by Analog
116
Multi-Speed Operation
117
Communication Mode Controls the Inverter
118
