Example:
Following you can find the typical interrogation hexadecimal bytes for logger slave
number 1:
01 03 00 00 00 46 C4 38 0D
See below a typical configuration for a logger:
Byte #
Modbus address
data
variable
decimal
0
01
slave
1.0
0
03
function
3.0
0
8C
Comput
140.0
1
40001
43FA8000
ID
501.0
2
40003
41480000
Bat
12.5
3
40005
41800000
Hour
16.0
4
40007
41B00000
Minute
22.0
5
40009
41D00000
Day
26.0
6
40011
41200000
Month
10.0
7
40013
40E00000
Year
7.0
8
40015
00000000
v1 instantaneous
0.0
9
40017
00000000
v1 average
0.0
10
40019
00000000
TI30_1
0.0
11
40021
00000000
variance10_1
0.0
12
40023
00000000
V1 max
0.0
13
40025
00000000
v1 min
0.0
14
40027
00000000
V2 instantaneous
0.0
15
40029
00000000
V2 average
0.0
16
40031
00000000
TI30_2
0.0
17
40033
00000000
variance10_2
0.0
18
40035
00000000
V2 max
0.0
