 Register count (Reg Count): number of registers a Modbus request
should ask the Orbit for.
 Third line:
 Slave number (Slave #): slave ID of the Orbit 360.
7.5.5.5 GPS location
Go to [STATUS  GPS location] for information about the geographical location of the
met mast. The site coordinates are displayed in WGS 84 format.
Fig. 37. STATUS screen: Site Coordinates
The following information is displayed on this screen:
 First line:
 Latitude (e.g. 41º38.937’N).
 GPS finite state machine status (e): a two-digit number that
provides its current state ID of the GPS FSM (for technical support
and troubleshooting).
 Second line:
 Longitude (e.g. 000º53.593’W).
 GPS RX buffer (b): a two-digit number that shows the latest
number of bytes received by the GPS.
