 10 Frequency channels.
 15 Analog channels.
 6 Output channels used for:
 “External battery” V discontinuous power.
 Alarm outputs.
 1 terminal with 2.5V continuous supply.
 4 terminals with 5V discontinuous power (white circles).
 13 terminals with “External battery” voltage continuous power, labeled with ‘+’
symbol (red circles).
 23 terminals for reference connection, labeled with ‘-‘ symbol
 10 terminals with 5V continuous power, labeled with ‘5V’ symbol (blue circles).
The terminals are grouped according to Table 1.
Terminal group
Terminal
range
Description
Frequency Channels
1 to 30
Frequency sensor connection area
Modbus
31 to 32
Modbus RTU over RS485
RS485
33 to 42
RS485 sensor connection area
Ext. Com
43 to 46
External modem connection area
Analog Channels
47 to 92
Analog sensor connection area
Table 1. Orbit 360 terminals grouping
