KINTECH ENGINEERING
ORBIT 360 | USER GUIDE
72
Fig. 22. Logger data and time
*The data can be decoded applying any time offset to account for the local time,
if wanted.
 GPS status: shows the signal of the GPS receiver. In case of GPS failure, an X is
shown instead of the coverage bars.
Fig. 23. GPS status
 RS485 communication status: a flashing dot indicates RS485 communication
between the logger are the sensors connected to the digital buses.
Fig. 24. RS485 communication status indicator
 Modbus status:
Fig. 25. Modbus status indicator
