6 Installation
The Orbit 360 data logger should be installed inside an electric enclosure or shelter box
rated for outdoor use (IP66). Customers can buy the shelter box from any provider or
directly to Kintech Engineering. The enclosure will protect against weather and
intrusion the data logger, solar charger, battery as well as any other item inside of it.
The Orbit 360 data logger has four metallic hanging brackets in the back for simple
attachment to the metallic plate of the enclosure. Their orientation with respect to the
logger case can be adjusted by means of a screwdriver.
Fig. 11. Adjusting the logger hanging brackets
The hanging brackets can be placed horizontally, as described in Fig. 12 or vertically, as
shown in Fig. 13).
