2. MAKE SURE THE FUEL COCK
IS IN THE OPEN POSITION.
(1) Fuel Cock
(A) OPEN (B) CLOSE
(1) P.T.O Clutch Lever
(2) Range Gear Shift Lever (Hi-Lo)
“HIGH SPEED”
“LOW SPEEDED”
3. PLACE THE P.T.O CLUTCH LE-
VER IN “NEUTRAL” POSITION.
4. PLACE THE RANGE GEAR
SHIFT LEVER (HI-LO) IN “NEU
-
TRAL” POSI-TION.
MAIN GEAR SHIFT LEVER & HI-LO
GEAR SHIFT LEVER
The main gear shift lever pattern is
in the form of an "H". The hi-lo gear
shift lever moves two stages, "high"
and "low". By combination and use of
the main gear shift lever and the hi-
lo gear shift lever, it is possible to ob-
tain four speeds forward and reverse
in "high" range and four speeds for-
ward and reverse in "low" range, or
a total of eight speeds forward and
eight speeds reverse.
621O502A
621O503A
