Section 11

Parts List

20479307

2-2012/Rev 04

11-9

Table 11-5

Hydraulic Piston Assembly

05132253

Item

Part

Number Description Quantity

1 05132261 Hydraulic Ram Piston, 4.03 1

2 05074380 Plunger Retainer Pin, Clevis, .25 12

3 05049887 Set Screw, Socket, 3/8-16 x 3/8 2

4 10148757 Check Valve 2

5 49877509 Adhesive, Thread Locker --

6 05088364 Flat Snap Ring, .032 x .375 x 2.010 2

7 05049994 Backup Ring, 1.50 x 1.25 2

8 05087713 O-Ring, 1.25 x 1.50 x .13 2

9 05117965 Seal Assembly 1

10 05117940 Bearing Ring 2

05115951 Rebuild Kit

Includes Items 4, 6, 7, 8,9 and 10
