14
3. Basic Operation Methods
3-2 Screen and Operation
3-2-1 Basic Screen and Operation
The touch-screen display enables selecting Display Modes and settings with the
touch of your nger.
Measurement Screen
The Measurement screen is displayed (for 2 seconds) after the power is turned ON, and
the dark calibration is made.
When the dark calibration is complete, the Display Mode Selection screen is displayed.
Select the desired display mode and the selected measurement screen is displayed.
Press the Measuring Button to make a measurement after setting the measuring mode
ambient or ash light) and relevant settings in Tool o.
* Pressing the Menu Button
6
returns the meter to the Display Mode Selection screen.
* The display changes depending on the set measuring mode.
* For this description, all icons and menus are displayed.
1
2 3
4
5
6
7
8
9
Measuring Screen in Text Mode
10
11
To Next Page
