4. Setting the Measuring Conditions
4-3-3 Displaying in Spectrum Comparison
[Spectrum Comp.] Mode
isplays the current measured value plus up to two selected values from the meters
memory for comparison.
Operation
1.
Touch the [Spectrum Comp.] icon on the Display Mode screen.
The Spectrum Comp. screen will be displayed. (
¨
P28)
2.
Touch the [Measuring Mode] icon.
The Measuring Mode Selection screen will be displayed. Select the desired
measuring mode to use. (
¨
P22)
3.
Touch the [Exposure Time] indication in the Measurement screen.
Set the exposure time to Auto, 0.1 sec, or 1.0 sec during ambient light
measurement. (
¨
P24)
[Measuring Mode] Icon
Memory Selection Icon
Line raph isplay
FF chec bo
isplay Mode Icon
Spectrum Comparison
isplay
Color temperature
display area
Current Measurement
Spectrum Comp. Screen
posure Time Indication
To Next Page
