39
Setting
4. Press either or key to select
[SINGLE FRAME] / [DOUBLE FRAME].
SPEED NORMAL
SYNC INT SYNC
MENU
MEAS
SYNC FRAME
DOUBLE FRAME
ANGLE 1˚
SYNC FRAME
SINGLE FRAME
DOUBLE FRAME
5. Press
ENTER
key.
When the synchronous frame is set, the MENU - MEAS
screen appears again on the LCD.
By pressing the
ESC
key, the setting is canceled and
the MENU - MEAS screen appears again on the LCD.
The display format setting is saved even after the power
switch is turned OFF (O).
SPEED NORMAL
SYNC INT SYNC
MENU
MEAS
SYNC FRAME
DOUBLE FRAME
ANGLE 1˚
6. Press
ESC
key.
The MENU screen appears again on the LCD.
7. Press
ESC
key.
The MEAS screen appears again on the LCD.
3. Press either or key to select [SYNC
FRAME] and then press
ENTER
key.
The MENU - MEAS - SYNC FRAME screen appears on
the LCD.
The synchronous frame selection screen appears.
SPEED NORMAL
SYNC INT SYNC
MENU
MEAS
SYNC FRAME
DOUBLE FRAME
ANGLE 1˚
SYNC FRAME
SINGLE FRAME
DOUBLE FRAME
