12
Names and Functions of Parts
Names of Each Part
(6) Objective
lens
(7) Focus
adjustment
ring
(15) Screw holes
for fixing
(3) USB connector
Handle
(9) LCD screen
(12) Finder
(11) Measurement
button
(8) Focus distance scale
Inside finder
(14) Aperture
(16) Vertically
synchronized signal
input terminal
(2) AC adapter input
terminal
(1) Power switch
(5) Measurement
angle selector
(4) RS-232C connector
(10) Key panel
(13) Diopter
adjustment
ring
CS-3000HDR/CS-3000/CS-2000Plus
CS-2000Plus only
