Operating Instructions 10/2020 2010045v10
ATTENTION
Locked connection
For CCS charging, the electric vehicle locks the plug. If the user wants to
remove the plug from the vehicle, it may be necessary to unlock all doors of
the EV or to press the "Unlock Charge Connector But- ton" on the vehicle
key, if present.
ATTENTION
End of charging
The charging process is stopped without user interaction:
When the charging station's electric vehicle indicates that charging is
complete. When the maximum charging time set by the site operator/owner
has been reached. If the battery is not fully charged, a new charging process
can be started.
6.8.8 Authentication after loading
If charging is not terminated with the RFID card or with an RFID card from the same group with which charging
was started, the charging cable remains locked to the station. Hold the RFID card in front of the card reader
with which charging was started or terminate charging remotely (with OCPP).
If the master card functionality is used, you can also use these cards to release the charging station lock.
The group function is a function of the OCPP protocol and is managed and the responsibility of the operator
(CPO).
6.8.9 Charging point reserved
If the charging station is connected to a backend,
the individual charging points can be reserved for
specific users. As soon as a reservation is pending,
this charging point is no longer available. The
reservation expires as soon as the expiry time has
been exceeded or the corresponding user has
authorised himself at this charging point.
Fig. 19: Charging point reservation using the DC
charging outlet "CCS" as an example
