Kramer VS-42UHD User Manual

56 VS-42UHD - Protocol 3000
13.3.2.2 ROUTE
Functions Permission Transparency
Set:
ROUTE
End User Public
Get:
ROUTE?
End User
Public
Description Syntax
Set: Set layer routing
#ROUTESP
layer,dest,src
CR
Get: Get layer routing
#ROUTE?SPlayer,destCR
Response
~nn@ROUTESP
layer,dest,src
CR LF
Parameters
layer – 1 (video)
dest – for video layer: 1 (HDMI Out 1), 2 (HDMI Out 2)
src – for video layer:
1
(HDMI In 1),
2
(HDMI In 2),
3
(HDMI In 3),
4
(HDMI In 4)
Response Triggers
Notes
The get command identifies input switching on Step-in clients
The set command is for remote input switching on Step-in clients (essentially via by the Web)
K-Config Example
Set the remote input switching of HDMI In 3 to HDMI Out 1:
“#ROUTE 1,1,3”,0x0D
