VS-42UHD - Protocol 3000 55

13.3.2 Switching/Routing Commands

Command Description

MTX-MODE?

Get switch mode

ROUTE

Set/get layer routing

VID

Set/get video switch state

13.3.2.1 MTX-MODE

Functions Permission Transparency

Set: – – –

Get:

MTX-MODE?

End User

Public

Description Syntax

Set: – –

Get :

Get auto-switch mode

#MTX-MODE?SPoutput_idCR

Response

~nn@MTX-MODESP

output_id,mode

Parameters

output_id: 1 (Out1), 2 (Out2)

mode

(manual),

(auto priority),

(auto last connected)

Response Triggers

After execution, a response is sent to the com port from which the Get was received

After execution, a response is sent to all com ports if MTX-MODE was set by any other external control device

(button press, WEB, device menu and similar)

K-Config Example

Get auto switch mode of Out 2:

“#MTX-MODE? 2,0”,0x0D

Kramer VS-42UHD User Manual
