VS-88H2 – Using Embedded Web Pages
34
Setting Audio Follow Video (AFV)/Audio Breakaway Mode
This section contains information on switching Audio Follow Video (AFV)/Audio Breakaway
Mode.
indicates output is AFV mode.
indicates output is Breakaway mode.
To set audio breakaway mode:
1. In the Navigation pane, click Switching.
The Switching page appears (Figure 18).
2. Select the AFV tab.
The Audio-follow-video tab is displayed (Figure 18).
3. Click the AFV/Breakaway ( ) icon.
The AFV/Breakaway icon changes to and the output changes to audio breakaway
mode.
To set audio follow video (AFV) mode:
1. In the Navigation pane, click Switching.
The Switching page appears (Figure 18).
2. Select the AFV tab.
The Audio-follow-video tab is displayed (Figure 18).
3. Click the AFV/Breakaway ( ) icon.
The AFV/Breakaway icon changes to and the output changes to audio follow video
mode.
(gray colored) indicates that the device is in the auto-switch mode and AFV status cannot
be altered.
Setting the AFV mode icons to AFV or Breakaway modes reflects the next switching step and
not the current status.
When the unit moves from breakaway to audio follow video switching mode, all audio switch
settings reset according to the video switch settings.
