Switching ARC to an Input
To switch ARC to an input:
1. In the Navigation pane, click Switching.
The Switching page appears (Figure 18).
2. Select the Audio break away ( ) tab.
The Audio break away tab is displayed (Figure 26):
3. Check the ARC check boxes to ARC-enable selected outputs (under the Audio Outputs
column).
EXAMPLE:
Output 2 and 4 are checked (ARC-enabled) so they can be switched as ARC signals.
Figure 28: Switching Page – Output 2 and 4 ARC-Enabled
Make sure that the acceptor on the output side has ARC capabilities
(see Enabling ARC Input on page 36).
