13 WHEELS, TIRES 103
101999-10
– Take the motorcycle off of the front wheel stand. ( p. 72)
– Pull the front wheel brake and push down hard on the fork several times to align the
fork legs.
–
Tighten screws
.
Guideline
Screw, fork stub M8 15 Nm
(11.1 lbf ft)
Finishing work
– Take the motorcycle off of the rear wheel stand. ( p. 71)
13.3 Removing rear wheel x
Preparatory work
– Raise the motorcycle with the rear wheel stand. ( p. 70)
102000-10
Main work
– Press the brake caliper by hand on to the brake disc in order to press back the brake
piston.
–
Remove screw
and pull wheel speed sensor
out of the hole.
–
Remove nut
. Remove chain adjuster
.
